The working principle of electric oil heater
-
2019-12-30
-
0
The working principle of electric oil heater
It is mainly composed of sealed electric heating element, metal heating tube, iron heat sink, temperature control element, power switch, indicator light, etc. It is a kind of safe and reliable space heater. This heater is installed in the heat pipe heat pipe inside the cavity, the chamber around the electric heating tube filled with heat oil. When the power supply, the heating tube around the heating oil is heated, rose to the upper part of the cavity, along the heat pipe or heat sink convection circulation, through the cavity wall surface heat radiation, thus heating the space environment. The air-cooled heat-conducting oil is lowered to the periphery of the heating tube and heated to start a new cycle. This heater is generally equipped with bimetallic temperature control components, when the oil temperature reaches the set temperature, the temperature control element will disconnect the power supply.
Features: The use of electric heating gasification oil heating, power from 1500-2500 watts range, shape a bit like the north of the heating blade box, the price of roughly four or five hundred dollars. The oil heating effect is very good, the basic to meet a medium-sized living room, bedroom heating, oil-type insulation effect is excellent, closed within 2 hours can still maintain the indoor temperature, it is particularly suitable for use in the bedroom at night 11 o'clock boot, regular 3 hours, basically can be maintained until dawn. The drawback is that the volume is too large, start more slowly. But the plus point: the disadvantage is the advantage of slow you do not feel more security peace of mind, security is the most important, but the most critical is the cooling effect and speed to match.
What are the advantages of electric oil?
Electric oil temperature is adjustable, to reach the set temperature will automatically power off, electric oil heater heating is particularly clean, and no noise, the heating effect is better, and more waterproof, suitable for bedrooms and bathrooms, and large Some brands of oil heater are equipped with a drying rack, the user can bake clothing, especially the rainy weather heater oil heater is even better.
Note the use of electric oil
In the use of electric oil heater heater, be sure to stand upright, because it is through the lower end of the heat pipe to heat the surrounding heat transfer oil, heat conduction oil in the flow tube to transfer heat. If the inverted, flat or oblique release, it will cause air burning, burning heat pipe. Special emphasis is strictly prohibited in the use of electric oil on the quilt cover clothing, such as clothing can not put more wet clothes. Temperature control switch should always check whether it can play a normal temperature at the corresponding turn on and off the heater, the stalls of the lamp must be positive signs of integrity.
Electric oil heater heater for living room heating, the air should be as close to the location of convection, so both warm and energy saving. As the radiator type oil heater in the work of the surface temperature can be as high as 85 degrees Celsius, for the bedroom heating, should try to avoid the person's head. If you have children in your home, place them in a place that is not easily accessible to children, or add protective equipment around them to prevent children from burning.
